Switchgear

• Silicone diode rectifying air-cooled, converting AC power to DC power for railway traction. The 6-phase 12-pulse rectifier was modularized so that it could be provided in an orderly manner in the enclosure.
• Eight pairs of heat sinks and eight thyristors were configured to be connected to each three-phase bus bar as a group. The structure was simplified to prevent enlargement of the volume.

SPECIFICATION

• KS C IEC 60146-1-1 2002 반도체 컨버터-일반요구사항 및 선전류 컨버터-제1-1부
• KS T 1002 수송 포장 계열 치수
• KS C IEC 61850 변전소 통신 네트워크 및 시스템
